How to upgrade AHF (TFA and ORACHK/EXACHK) using ahfctl (and patch it for Log4j vulnerability with version 21.3.4.0.0)

How to upgrade AHF (TFA and ORACHK/EXACHK) using ahfctl (and patch it for Log4j vulnerability with version 21.3.4.0.0)

By: Manoj Kumar
Topic: Oracle | Posted: Dec 17, 2021 at 10:32 AM EST

Recently we upgraded the Autonomous Health Framework (AHF) to the latest version and I found the new AHFCTL command line very helpful and easy to upgrade AHF.

AHFCTL command-line utility starts from version 21.1 version.

Here are the steps:

1. Download the latest patch to the patch location.

[root@oda-base0 stage]# pwd
/u01/stage
[root@oda-base0 stage]# ls -lrt
total 402584
-rw-r--r-- 1 root root 411834022 Dec 15 19:44 AHF-LINUX_v21.3.4.zip
[root@oda-base0 stage]#

2. Check the current version of AHF using the below command: ahfctl statusahf

[root@oda-base0 stage]# ahfctl statusahf


.------------------------------------------------------------------------------------------------.
| Host     | Status of TFA | PID   | Port | Version    | Build ID             | Inventory Status |
+----------+---------------+-------+------+------------+----------------------+------------------+
|oda-base0 | RUNNING       | 18822 | 5000 | 21.3.3.0.0 | 21330020211213022521 | COMPLETE         |
'----------+---------------+-------+------+------------+----------------------+------------------'
------------------------------------------------------------

Master node = oda-base0

orachk daemon version = 21.3.0

Install location = /opt/oracle/dcs/oracle.ahf/orachk

Started at = Fri Nov 19 10:40:14 EST 2021

Scheduler type = TFA Scheduler

Scheduler PID:  18822
------------------------------------------------------------
ID: orachk.autostart_client_oratier1
------------------------------------------------------------
AUTORUN_FLAGS  =  -usediscovery -profile oratier1 -dball -showpass -tag autostart_client_oratier1 -readenvconfig
COLLECTION_RETENTION  =  7
AUTORUN_SCHEDULE  =  3 2 * * 1,2,3,4,5,6
------------------------------------------------------------
------------------------------------------------------------
ID: orachk.autostart_client
------------------------------------------------------------
AUTORUN_FLAGS  =  -usediscovery -tag autostart_client -readenvconfig
COLLECTION_RETENTION  =  14
AUTORUN_SCHEDULE  =  3 3 * * 0
------------------------------------------------------------

Next auto run starts on Dec 16, 2021 02:03:00

ID:orachk.AUTOSTART_CLIENT_ORATIER1


3. Set Software stage location: ahfctl set upgrade -swstage

[root@oda-base0 stage]# ahfctl setupgrade -swstage /u01/stage/
AHF autoupgrade parameters successfully updated Successfully synced AHF configuration refreshConfig() completed successfully.  NOTE: you don't need to unzip the file

4. Upgrade AHF using ahfctl upgrade command:

[root@oda-base0 stage]# ahfctl upgrade

/u01/stage/AHF-LINUX_v21.3.4.zip successfully extracted at /u01/stage/
AHF software signature has been validated successfully

AHF Installer for Platform Linux Architecture x86_64

AHF Installation Log : /tmp/ahf_install_213400_77222_2021_12_16-15_05_05.log

Starting Autonomous Health Framework (AHF) Installation

AHF Version: 21.3.4 Build Date: 202112151432

AHF is already installed at /opt/oracle.ahf

Installed AHF Version: 21.3.3 Build Date: 202112130225

Upgrading /opt/oracle.ahf

Shutting down AHF Services
Stopped OSWatcher
Nothing to do !
Shutting down TFA
oracle-tfa stop/waiting
Killing TFA running with pid 52188 gracefully
. . . . .
Killing TFA running with pid 52188
. . .
Successfully shutdown TFA..

Starting AHF Services
Starting TFA..
oracle-tfa start/running, process 83660
Waiting up to 100 seconds for TFA to be started..
. . . . .
Successfully started TFA Process..
. . . . .
TFA Started and listening for commands
No new directories were added to TFA
Directory /u01/app/grid/crsdata/oda-base0/trace/chad was already added to TFA Directories.


INFO: Starting orachk scheduler in background. Details for the process can be found at /opt/oracle.ahf/data/oda-base0/diag/orachk/compliance_start_161221_150721.log


AHF is successfully upgraded to latest version

.-----------------------------------------------------------------.
| Host      | TFA Version | TFA Build ID         | Upgrade Status |
+-----------+-------------+----------------------+----------------+
| oda-base0 |  21.3.4.0.0 | 21340020211215143236 | UPGRADED       |
|-----------+-------------+----------------------+----------------'

Moving /tmp/ahf_install_213400_77222_2021_12_16-15_05_05.log to /opt/oracle.ahf/data/oda-base0/diag/ahf/

  [root@oda-base0 stage]# tfactl status

.-------------------------------------------------------------------------------------------------.
| Host      | Status of TFA | PID   | Port | Version    | Build ID             | Inventory Status |
+-----------+---------------+-------+------+------------+----------------------+------------------+
| oda-base0 | RUNNING       | 83922 | 5000 | 21.3.4.0.0 | 21340020211215143236 | COMPLETE         |
|-----------+---------------+-------+------+------------+----------------------+------------------'
